Hobbywing Quicrun Fusion Pro Elite 2300kV 2-4S 30120500

The Hobbywing QuicRun Fusion Pro Elite is the latest generation of the popular Fusion series, combining motor and ESC in an ultra-compact 2-in-1 design. At only 48.5mm in total length, it is 9.5mm shorter than the QuicRun Fusion Pro version and even 1.3mm shorter than the AXE 540.

Thanks to FOC drive technology (Field-Oriented Control), the Fusion Pro Elite delivers extremely strong low-speed torque as well as exceptionally smooth and quiet operation. This makes precise crawling and controlled driving possible even in demanding terrain.

The ESC supports 24S LiPo and provides a maximum continuous output current of 50A, ensuring stable and consistent power delivery without interruptions. Combined with intelligent torque management and closed-loop control for speed and power, the Fusion Pro Elite offers maximum control on any surface.

Features

  • 2-in-1 design: motor & ESC combined, only 48.5mm length
  • 9.5mm shorter than the QuicRun Fusion Pro, 1.3mm shorter than the AXE 540
  • FOC drive: powerful low-speed torque & quiet operation
  • Maximum continuous current: 50A with 24S LiPo
  • Intelligent torque & speed control for precise handling
  • Drag Brake and other parameters adjustable in real-time via AUX channel
  • 5 operating modes
  • Fully waterproof & dustproof according to IP67



The integrated design of the ESC makes the overall volume is only the size of 550 motor, and the overall weight is only 201g, which makes the layout and wiring of car frame simpler and more beautiful, perfectly solves the difficulty of wiring due to the small internal space of rock crawler.

The Fusion system adopts FOC driving mode, low speed
torque is strong. It runs smoothly at very low speed,
outstripping ordinary sensored power system, even better
than brushed power system. Moreover, the motor is extremely
silent when it is running. The driving noise which annoys driver
disappears. It is the best choice for rock crawler.



Professional Drag Brake Adjustments
& Super Parking Capacity

8 gears of drag brake force and 9 gears of drag brake rate
can meet different car models, different fields and different
controlling habits. The maximum drag brake force is about
twice that of ordinary brushless power of the same size,
providing super strong parking capacity on slope
