Savox SV-0258MG+ Digital High Voltage Brushless / Steel Gears

The Savox SV-0258MG+ is a low-profile digital high-voltage servo designed for RTR vehicles, 1/10 touring cars and compact RC chassis where reliable steering performance, low current draw and space-saving installation are important. With 8.0 kg/cm torque at 7.4V and a speed of 0.11 sec/60° at 7.4V, this servo offers strong and responsive control in a compact low-profile format.

The DC core motor provides smooth and predictable operation, while the digital high-voltage controller delivers precise and consistent steering response. The hybrid composite and metal gear train offers a practical balance between durability, smooth operation and efficiency, making the SV-0258MG+ a reliable upgrade for many ready-to-run vehicles.

The composite low-profile case saves space inside the chassis, while the electronics are designed to work efficiently with entry-level ESC/BEC systems. With current draw limited to around 1.5A, the SV-0258MG+ helps reduce the risk of ESC shutdowns or voltage-related interruptions in suitable RTR setups.

Thanks to its 25T spline, high-voltage compatibility, compact low-profile dimensions and water/dust-resistant protection, the SV-0258MG+ is a smart choice for RC drivers looking for reliable Savox performance in 1/10 touring cars, RTR vehicles and other compact RC car applications.

Features:

• Low-profile digital high-voltage servo
• 8.0 kg/cm torque at 7.4V
• Speed 0.11 sec/60° at 7.4V
• DC core motor for smooth and predictable operation
• Digital HV technology for accurate positioning and reliable response
• Composite + metal gears for durability and smooth operation
• Low-profile composite case for space-saving installation
• Designed for entry-level ESC/BEC systems
• Current draw limited to around 1.5A for stable RTR operation
• Water/dust-resistant protection
• 2 ball bearings for smooth and stable output support
• 25T spline output shaft
• 10-bit PCB
• Compatible with Sanwa SSR
• Ideal for RTR vehicles, 1/10 touring cars and compact RC car chassis

Technical Specifications:

• Model: SV-0258MG+
• Servo Type: Low-profile digital high-voltage servo
• Motor Type: DC core motor
• Gear Type: Composite + metal gears
• Case Type: Composite case
• Operating Voltage: 6.0V – 7.4V
• Torque @ 6.0V: 6.5 kg/cm
• Torque @ 7.4V: 8.0 kg/cm
• Speed @ 6.0V: 0.13 sec/60°
• Speed @ 7.4V: 0.11 sec/60°
• Quiescent Current: 6 mA
• Rated Current: 180 mA
• Blocking Current: 1800 mA
• Protection: Water/dust resistant
• Positioning: VR potentiometer, direct drive
• Technology: Digital HV
• PCB Board: 10-bit
• Bearings: 2x ball bearings
• Spline: 25T, 6.0 mm
• Dimensions: 40.8 x 20.2 x 27.75 mm
• Weight: 36 g
• Compatibility: Sanwa SSR
• Connector: JR universal connector with coloured lead

Packaging Content:

• 1x Savox SV-0258MG+ low-profile digital high-voltage servo
• Standard servo mounting hardware
• Standard servo accessories
