SRT Servo DHW35 Digital Waterproof 35.0kg/0.10sec @8,4V

€ 78,89 inc. BTW

Op voorraad

Qty
Stel een vraag over dit product

SRT Servo DHW35 Digital Waterproof 35.0kg/0.10sec @8,4V

Brandname SRT
Servo Technology Digital Low Voltage

Brandname SRT
IType: Digital
Bearing: Dual
Motor Type: Coreless
Gear Type: Metal
Gear Material: Titanium & Steel
control system: pulse width control
working frequence: 1520μs / 330hz
operating voltage: dc6.0-8.4v
operating temperature range: -10 to + 60 degree
operating speed (6.0v): 0.15 sec/60 degrees at no load
operating speed (7.4v): 0.12 sec/60 degrees at no load
operating speed (8.4v): 0.10 sec/60 degrees at no load
stall torque (6.0v): 25.0kg.cm (347.2 oz/in)
stall torque (7.4v): 30.0kg.cm (416.6 oz/in)
stall torque (8.4v): 35.0kg.cm (486.1 oz/in)
potentiometer drive: direct drive
dimensions: 40.7×20.5×38.6 mm /1.60×0.81×1.52 in
weight: 82.5g (2.91 oz)
connector wire length: jr 360 mm
Connector type JR
Spline size 25T Spline
