€ 63,90 inc. BTW

Op voorraad

Stel een vraag over dit product

Absima CR4S 4Ch 2.4Ghz Radio set + 2 Receivers 2000103

The “CR4S” is a 4-channel remote control including 2 receivers, which uses the latest AFHDS 2.4GHz “ANT” frequency hopping technology from ABSIMA.

Lightweight and compact design, as well as comfortable and ergonomic shape. In addition, the remote control has a “beginner mode” and is therefore also suitable for pilots with less experience and also children.
The included receivers have a very compact design with a size of 30.2*18.0*13.0mm and fit in almost every receiver box.

FEATURES

Description of the channels (the transmitter has 4 channels which are assigned as follows):
CH1: Steering wheel
CH2: Throttle lever (Trigger)
CH3: 3-position toggle switch
CH4: Push button

Reverse function (REV): This function can be used to set the direction of rotation of the steering servo/motor.
Trimming (TRIM): Adjustment of the straight run and throttle neutral position.
Dual Rate function (D/R): The steering angle and also the motor rotation power can be increased or reduced by operating this rotary knobs.
Failsafe function: This function determines what the receiver should pass on if the signal to the transmitter is lost (e.g. emergency braking).
Beginner modus: This function is intended for newcomers. In this mode the motor power is automatically reduced to 50%.
SPECIFICATIONS

Radio CR4S:

Channels: 4
2.4GHz Protocol: ANT
Distance: >150m
Battery (not included): 4*AAA 1.5 – 6V DC
Low V Warning: <4.2V (only NiMH)
Using LiPo TX battery possible: Yes (only LiPos with built-in low V protection)
Charging interface: No
Antenna type: Single antenne
Temperatur range: -10°C – +60°C
Size: 118*73*145 mm
Weight: ca. 130g

Receiver R4WP Micro (2020016):

Channels: 4
Antenna type: external single antenna
Waterproof: Yes
Power: 3.5-8.4V
Failsafe: Yes (in connection with radio)
Temperatur range: -10°C – +60°C
Weight: 5g
Size: 30.2*18.0*13.0 mm

SET INCLUDES

1* 4-Channel radio “CR4S”
2* 4-Channel receivers
1* Antenna tube
1* Manual (DE/ENG/FR)
